H-Series

10+ Years Experience in 2000kW-3600kWDiesel Engine Manufacturing.
20+ Years Experience in Over 300kW DieselEngine Manufacturing.
30+ Years Experience in the Diesel Engine &Generator Set Field.
Inventing the World's First V-type 14-Cylinder, 16-Cylinder, and 20-Cylinder Engines with Cylinder Diameters of 128-132-135mm.
Reliable
Low Emissions
Low Fuel Consumption
Low Maintenance Costs

Model OUTPUT	HPG1375E-HV10.5-50C	HPG1875E-HV10.5-50C	HPG2200E-HV10.5-	HPG2500E-HV10.5-
Voltage [V]	10.5kV

Standby Power(LTP)[kVA]	1375	1875	2200	2500
Standby Power(LTP) [kW]	1100	1500	1760	2000
Prime Power(PRP) [kVA]	1250	1688	2000	2250
Prime Power(PRP) [kW]	1000	1350	1600	1800
Continuous Power(COP)[kVA]	1125	1265	1600	2025
Continuous Power(COP)[kW]	900	1012	1280	1620
GENERAL DATA
Phase	3
Power Factor	0.8
Maximum Altitude Requirement[m]	1000
Fuel Consumption @ Standby Power [g/kWh]	196.54	197.34	193.37	188.26
Frequency[Hz]	50
Dimensions (WxHxL)[m]	2.6x3.0x5.1	2.6x3.0x6.6	2.6x3.0x6.9	2.6x3.1x7.2
Weight [kg]	9685	16300	18000	20500
Ingress Projection	IP23

Model OUTPUT	HPG2750E-HV10.5-50C	HPG3300E-HV10.5-50C	HPG3438E-HV10.5-50C	HPG3750E-HV10.5-50C
Voltage [V]	400

Standby Power(TP)[kVA]	2750	3300	3438	3750
Standby Power(LTP) [kW]	2160	2640	2750	3000
Prime Power(PRP) [kVA]	2500	3000	3125	3375
Prime Power(PRP) [kW]	2000	2400	2500	2700
Continuous Power(COP)[kVA]	2125	2650	2650	2650
Continuous Power(COP)[kW]	1700	2650	2120	2120
GENERAL DATA
Phase	3
Power Factor	0.8
Maximum Altitude Requirement [m]	1000
Fuel Consumption @ Standby Power [g/kWh]	196.49	193.05	193.03	193.02
Frequency[Hz]	50
Dimensions (WxHxL)[m]	2.6x3.1x7.2	2.8x3.1x8.25	2.8x3.1x8.25	2.8x3.1x8.45
Weight [kg]	21000	23600	24500	26500
Ingress Projection	IP23

　　The data in this document will be updated continuously due to the technological development of our company.If users need the latest technical information,please contact our company or our cooperating agents and OEM companies to obtain it.The data in this document does not serve as any legal certificate of the contract text.Our company has the right to change and interpret these data without any notice.

Version: 28-12
